Copy Gasoline/Petrol Generator Engine for Honda  with 2HP-35HP Engine

Productivity:
5000/Month
Place of Origin:
Ningde, China
Supply Ability:
5000/Month
  • Mr. Catherine Zhou

Basic Info

Model No.:  HYE154-192

Product Description

Model NO.: HYE154-192 Starting: Recoil+E-Start Power: 2HP-35HP Color: Customerlize Cooling system: Air Cool Transport Package: Carton Origin: Ningde, China Output Type: AC Single Phase Phase: Single-Phase Standard: Standard Package: Carton Trademark: HONY POWER Specification: small HS Code: 8502200000 HONDA COPY Gasoline Generator Engine OVERVIEW: 1. We continuously improve the design of cylinder, air-cleaner, muffer and fuel tank to make this product to fit any purpose.
2. Our advanced transistor magnet ignition system make it very easy to start the engine.
3. We reduce the environment pollution to the lowest through the advanced design of muffler and air-cleaner
4. To saticfy any of your repuirements. we can provide you multiform design of same model. FEATURE: 1.Air cooled Gasoline Engine, with Recoil +E-Starting
2.Compact and Portable Power for Emergency and Home Standby Use
3.Large Mufflers and Less Fuel Consumption
4.Color Box Package for Choice
5.Capacity Discharge ignition(CDI) System make sure easy and quick starting
6.AC Single Phase/Three Phase portable Power range from 0.5-20KW
Product Specification:
                       HONY POWER  Gasoline Engine
Model HY90 HY160 HY200 HY210 HY270 HY390 HY420
Engine type HY154F HY168F HY168-1F HY170F HY177F HY188F HY190F
Bore x Stroke 154*38mm 168*45mm 168*52mm 170*52mm 177*58mm 188*64mm 190*64mm
Displacement 83cc 163cc 196cc 210cc 269cc 389cc 420cc
Compression 7.7:1 8.5:1 8.5:1 8.5:1 8.2:1 8.0:1 8.0:1
ratio
Max out(HP) 2.6 5.5 6.5 7 9 13 15
Max out(KW) 2 4.1 4.9 5.3 6.8 9.6 11.3
Oil Capacity 0.37L 0.6L 0.6L 0.6L 1.1L 1.1L 1.1L
Fuel Capacity 1.6L 3.6L 3.6L 3.6L 6.0L 6.5L 6.5L
Min,Fuel 450g 295g 280g 280g 280g 275g 275g
Consumption
( g-hp/H )
Dimensions 300x290x280   510x400x 510x430x 510x430x
(LxWxH) 390x330x350  460 475 475

Net weight 10.6kg 15kg 16kg 17kg 28kg 33kg 34kg
Ignition system non-contact transistorized  ignition(TCI)
Starting System recoil and hand-operated
Air cleaner   semi-dry,oil bath,dual,double  silent and cyclone type
Spark plug F6RTC F6RTC F7RTC F7RTC F7RTC F7RTC F7RTC
20FT Quantity 630 630 630 630 268 268 268
set
40HQ Quantity 1505 1505 1505 1505 652 652 652
sets
Copy Gasoline/Petrol Generator Engine for Honda with 2HP-35HP EngineCopy Gasoline/Petrol Generator Engine for Honda with 2HP-35HP Engine
Copy Gasoline/Petrol Generator Engine for Honda with 2HP-35HP Engine
Company Profile:
Copy Gasoline/Petrol Generator Engine for Honda with 2HP-35HP Engine

Contact us if you need more details on Gasoline Engine. We are ready to answer your questions on packaging, logistics, certification or any other aspects about for Honda Engine、Generator Engine. If these products fail to match your need, please contact us and we would like to provide relevant information.
